Product Features
LINISHALL Heavy Duty Belt Grinders
• Fully guarded with hinged flap on top for platen linishing
• Front dust chute
• Rear dust extractor port
• Front eye guard
• Tool rests
• Adjustable (by swivelling about pivot point) for height
• Simple tracking & belt change
• 1 or 3 Phase options as indicated by model number in Specifications table below
• 4 belt sizes:
1220 x 100mm
2000 x 75mm
2000 x 150mm
2000 x 220mm
Slower speed machine avoids burning softer material such as wood, plastics etc. Can also be used as a bench mounted machine by removing the included delta stand
Specifications
| Model | Belt Size | Motor | Motor Speed (rpm) | Belt Linear Velocity (m/s) |
|---|---|---|---|---|
| 1220/100/P1 | 1220mm x 100mm | 1.5kW (2HP) | ||
| 2000/75/P1 | 2000mm x 75mm | 3.0kW (4HP) ~ 1Ph | 2800 | 30 |
| 2000/75/P3 | 2000mm x 75mm | 3.0kW (4HP) ~ 3Ph | 2800 | 30 |
| 2000/150/P3 | 2000mm x 150mm | 4.0kW (5HP) ~ 3Ph | 2800 | 30 |
| 2000/220/P3 | 2000mm x 220mm | 4.0kW (5HP) ~ 3Ph | 2800 | 30 |
